We are Proving the DMS-100 dust meter is an online dust analysis product independ- ently developed and produced by our company. Measurement Principle Measurement Range Flue Diameter Laser Component Sensitivity Indication Error Span Drift Analog Output Laser Back Scattering Method 0~500mg/m3(conventional range); 0~10g/m3(customized range) 0.5m~15m (customizable) 650nm, 7mW 1mg/m3 ≤±20% ±2%F.S. 1-way 4-20mA, Maximum load 800Ω, 2-way 4-20mA option Communication Interface RS485 Ambient Temperature (-20~45)℃ Ambient Humidity <100%RH, no condensation Flue Gas Temperature 0~150℃ (need to be customized for higher temperature) Human-PC Interaction Infrared remote controller + large LCD display Power Supply DC (24±2.4)V Power Approx. 3W Dimensions & Weight 158(W)×273(D)×158(H)mm, approx. 3kg Features: Laser back scattering principle eliminates the mechani- cal vibration of flue gas, the uneven temperature of the flue gas, the background stray light and other factors that interfere with the detection accuracy Single-end installation without optical alignment Modulated laser beam, greatly improve anti- interference ability Automatic gain control and temperature compensation Infrared remote control function, safer operation LCD display to read the dust concentration onsite 'No tools' onsite installation method, convenient installation, disassembly and cleaning Compact structure, low power consumption, approx. 3W Applications Thermal power generation, iron and steel metallurgy, petrochemical, cement production, pottery, waste incineration and other enterprises all kinds of power generation boilers, industrial kilns, industrial boilers soot emission monitoring and flue gas desulfurization and dust removal engineering monitoring and control occasions. Can be equipped with continuous smoke monitoring system (CEMS), or a single or several sets can be connected to a set of smoke monitoring network, sharing the same front-end platform. For More check our latest updates in our website: https://www.gpipl.com/
